PRODUCTS

Innovative Technology | Reliable Quality | End-to-End Service

ILS1000

iLinksView Network Management Platform

> Network management platform

> Discover devices automatically, such as switches, IPCs and NVRs

> Visual management of network topology

> Real-time device monitoring: Online/offline status and link status of devices

> Chart statistics: Visual and graphical statistics display

> Wide temperature range: -10°C to 55°C


  • 仕様
  • アクセサリ
  • ダウンロード
  • Intelligent Analysis

    Switch Statistics

    Switch online/offline statistics

    IP Device Statistics

    IP device online/offline statistics

    Port Usage

    Usage statistics of switch ports

    CPU Usages

    Display the top 9 switches with most CPU usages

    Total bandwidth of port

    Total bandwidth statistics of port

    Alarm Statistics

    IP conflict alarm, switch status alarm, terminal status alarm, loopback alarm, port congestion alarm

    Dynamic View

    Device Discovery

    Dahua managed switches
    Dahua terminal devices, such as IPC, NVR
    SNMP switches

    Network Topology

    Display managed switches
    Display unmanaged switches
    Display IP devices
    Display network link status

    Networking Mode

    Support discovery and identification of cascading, star, aggregation and other networking;

    Network Device

    Switch

    Display the detailed information of switches, such as name, mode, SN, IP, MAC and status.

    Terminal Device

    Display the detailed information of IPCs, NVRs and other devices, such as name, type, mode, IP, MAC, manufacturer and status.

    PoE Management

    Display the power consumption of switches, including total and used power consumption. And remotely control the PoE switch.

    Alarm Message

    Alarm Message

    Support IP conflict alarm, switch status alarm, terminal status alarm, loopback alarm, port congestion alarm

    System Management

    Maintenance

    One click to reset
    Support upload of upgrade package
    Support import and export of configuration file
    Support system log

    Web Management

    Support HTTPS and HTTP login

    Performance

    Supported Device

    1000 switches
    10,000 ports

    Performance

    Power Consumption

    15W

    Memory

    2 GB

    Ethernet port

    2 × 10/100/1000 M RJ-45 ports

    Indicator

    PWR indicator and SYS indicator

    Operating Temperature

    -10°C to 55°C (14°F to 131°F)

    Operating Humidity

    5%–95%

    Dimensions (L × W × H)

    155 mm × 135 mm × 30 mm (6.10" × 5.31" × 1.18")

    Weight

    1.6 kg (3.53 lb)
