IPC-HFW3441DG-AS-4G-EAU-B

4MP IR Fixed-focal Bullet WizSense 4G Network Camera

> 4-MP 1/3" CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light/IR LED.

> Sound and light alarm linkage. When the alarm is triggered, the sound and light will be linked.

> Built in high-performance 4G Module that suits all mobile networks. Installation is no longer limited to wired networks.

> Built-in PIR sensor that detects human body through passive infrared which is sensitive to body temperature.

> Built-in 8 GB eMMC memory chip that protects key records from being lost.

> Abnormality detection: Motion detection, video tampering, audio detection, SD card full, SD card error, network disconnection, IP conflict and illegal access.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; RS485:1 (Only report the information of solar battery, such as power and battery level), Supports max. 256 G Micro SD card; built in MIC and speaker; support two-way talk.

> IP67 protection.


  • Caractéristiques
  • Accessoires
  • Téléchargement
  • Camera

    Image Sensor

    1/3" CMOS

    Max. Resolution

    2688 (H) × 1520 (V)

    ROM

    128MB

    RAM

    256MB

    Scanning System

    Progressive

    Electronic Shutter Speed

    Auto/Manual 1/3 s–1/100,000 s

    Min. Illumination

    0.01 Lux@F1.6 (Color,30IRE)

    0.001 Lux@F1.6 (B/W,30IRE)

    0 lux (Illuminator on)

    S/N Ratio

    >56 dB

    Illumination Distance

    IR: 50 m (164.04 ft)
    Warm light: 30 m (98.43 ft)

    Illuminator On/Off Control

    Auto;Manual

    Illuminator Number

    1 (IR LED); 1 (Warm light)

    PIR Sensor Distance

    10 m (the height of device is 2.5 m, placed horizontally)
    5 m (the height of the device is 2 m, placed at an angle of 30° from the horizontal)

    Lens

    Lens Type

    Fixed-focal

    Lens Mount

    M12

    Focal Length

    2.8 mm; 3.6 mm; 6 mm

    Max. Aperture

    2.8 mm: F1.6
    3.6 mm: F1.6
    6 mm: F1.6

    Field of View

    2.8 mm: H: 102°; V: 54°; D:121°
    3.6 mm: H: 84°; V: 42°; D:101°
    6 mm: H: 52°; V: 48°; D:61°

    Iris Control

    Fixed

    Close Focus Distance

    2.8 mm: 0.9 m (2.95 ft)
    3.6 mm: 1.7 m (5.58 ft)
    6 mm: 3.2 m (10.50 ft)

    DORI Distance

    Lens

    Detect

    Observe

    Recognize

    Identify

    2.8 mm

    63.6 m (208.66 ft)

    25.4 m

    (83.33 ft)

    12.7 m

    (41.67 ft)

    6.4 m

    (21.00 ft)

    3.6 mm

    85.4 m (280.18 ft)

    34.2 m (112.20 ft)

    17.1 m

    (56.10 ft)

    8.5 m

    (27.89 ft)

    6 mm

    124.0 m (406.82 ft)

    49.6m (162.73 ft)

    24.8m

    (81.36 ft)

    12.4m

    (40.68 ft)

    Video

    Video Compression

    H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)

    Video Frame Rate

    Main stream: 2688 × 1520 @(1–25/30 fps )

    sub stream: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30

    fps)

    Sub stream 1: 1920 × 1080 @ (1–25/30 fps)

    Stream Capability

    3 streams

    Resolution

    4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 ×960 ); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

    Bit Rate Control

    CBR/VBR

    Video Bit Rate

    H.264: 32 kbps–8192 kbps
    H.265: 32 kbps–8192 kbps

    Day/Night

    Auto(ICR)/Color/B/W

    BLC

    Yes

    HLC

    Yes

    WDR

    120 dB

    Scene Self-adaptation (SSA)

    Yes

    White Balance

    Auto; natural; street lamp; outdoor; manual; regional custom

    Gain Control

    Auto

    Noise Reduction

    3D NR

    Motion Detection

    OFF/ON (4 areas, rectangular)

    Region of Interest (RoI)

    Yes (4 areas)

    Smart Illumination

    Yes

    Mirror

    Yes

    Privacy Masking

    4 areas

    Audio

    Built-in MIC

    Yes

    Built-in Speaker

    Yes

    Audio Compression

    G.711a;G.711Mu; G.726; PCM

    Alarm

    Alarm Event

    SD card error; SD card full; IP conflict; illegal access; motion detection; video tampering; audio detection; security exception; PIR alarm; external alarm; low battery alarm; light alarm; sound alarm

    Network

    Network Port

    RJ-45 (10/100 Base-T)

    Frequency

    LTE FDD:B1/3/5/7/8/20/28
    LTE TDD:B38/40/41
    WCDMA:B1/5/8
    GSM/GPRS/EDGE:B3/5/8

    SDK and API

    Yes

    Cyber Security

    Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade

    Network Protocol

    IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP

    Interoperability

    ONVIF (Profile S/Profile G); CGI; P2P

    User/Host

    20 (Total bandwidth: 80 M)

    Storage

    Bulit in eMMC (8 GB); FTP;SFTP; Micro SD card (support max. 256 GB); NAS

    Browser

    IE
    Chrome
    Firefox

    Management Software

    DSS; DMSS

    Mobile Client

    iOS; Android

    Certification

    Certifications

    CE-LVD: EN62368-1;

    CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;

    CE-RED: Radio Equipment Directive 2014/53/EU;

    FCC: 47 CFR FCC Part 15; Subpart B

    Port

    Audio Input

    1 channel (RCA port)

    Audio Output

    1 channel (RCA port)

    Alarm Input

    1 channel in: 5 mA 3–5 VDC

    Alarm Output

    1 channel out: 300 mA 12 VDC

    RS-485

    1 (Only report the information of solar battery, such as power and battery level)

    Power

    Power Supply

    12 VDC

    Power Consumption

    Sleep Mode: 0.03 W

    General Mode: 4 W

    Power Saving Mode: 2 W

    Max. (4G pulling stream+IR+speaker+warning light): 7.5 W

    Environment

    Operating Temperature

    –40 °C to +60 °C (–40 °F to +140 °F)

    Operating Humidity

    ≤ 95%

    Storage Temperature

    –40 °C to +60 °C (–40 °F to +140 °F)

    Protection

    IP67

    Structure

    Casing

    Metal + plastic

    Product Dimensions

    132 mm × 219 mm×179 mm (5.20" × 8.62" × 7.05")

    (L × W × H)

    Packaging Dimensions

    280 mm × 239 mm × 146 mm (11.02" × 9.41" × 5.75")

    (L × W × H)

    Net Weight

    680 g (1.50 lb)

    Gross Weight

    1180 g (2.60 lb)
