SD8A3440GA-HNV

4MP 40× Starlight IR NETWORK PTZ CAMERA

> 1/1.8" 4Megapixel STARVIS™ CMOS.

> 40× optical zoom.

> Starlight technology.

> IR distance up to 500 m.

> Auto-tracking.

> Perimeter protection.

> Face Detection.

> Metadata.

> SMD.

> IP67,IK10.


  • Specifiche
  • Accessori
  • Download
  • Camera

    Image Sensor

    1/1.8" CMOS

    Pixel

    4 MP

    Max. Resolution

    2560 (H) × 1440 (V)

    ROM

    4 GB

    RAM

    1 GB

    Electronic Shutter Speed

    1/1 s–1/30,000 s

    Scanning System

    Progressive

    Min. Illumination

    Color: 0.001 lux@F1.6
    B/W: 0.0001 lux@F1.6
    0 lux (IR light on)

    Illumination Distance

    500 m (1,640.41 ft) (IR)

    Illuminator On/Off Control

    Zoom Prio; Manual; Auto; Off

    Illuminator Number

    10 (IR)

    Lens

    Focal Length

    5.6 mm-223 mm

    Max. Aperture

    F1.6–F4.9

    Field of View

    H: 63.9°–2.1°; V: 37.3°–1.2°; D: 71.2°–2.4°

    Optical Zoom

    40×

    Focus Control

    Auto; semi-auto; manual

    Close Focus Distance

    1 m–5 m (3.28 ft–16.40 ft)

    Iris Control

    Auto

    DORI Distance

    Detect

    Observe

    Recognize

    Identify

    3,034.5 m (9,955.71 ft)

    1,198.6 m (3,932.41 ft)

    606.9 m (1,991.14 ft)

    303.4 m (995.41 ft)

    PTZ

    Pan/Tilt Range

    Pan: 0° to 360° endless
    Tilt: –30° to +90°, auto flip 180°

    Manual Control Speed

    Pan: 0°/s–240°/s

    Tilt: 0°/s–100°/s

    Preset Speed

    Pan: 0°/s–240°/s

    Tilt: 0°/s–100°/s

    Preset

    300

    Tour

    8 (up to 32 presets per tour)

    Pattern

    5

    Scan

    5

    Power-off Memory

    Yes

    Idle Motion

    Preset;Pattern;Tour;Scan

    PTZ Protocol

    DH-SD
    Pelco-P/D (Auto recognition)

    Intelligence

    Video Metadata

    Motor vehicle, non-motor vehicle, face, and human body detection; bounding box; optimization; capturing pictures; uploading high-quality face snapshots
    Motor vehicle attributes: License plate, plate color, vehicle type, vehicle color, vehicle logo, vehicle model/year, sun visor, seatbelt, smoking, calling, ornament, and annual inspection sticker

    IVS (Perimeter Protection)

    Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking

    Face Detection

    Supports face detection, face bounding box, optimization, capturing snapshots, uploading high-quality face snapshots, and enhancing face images. Attribute extraction is also supported, where 6 attributes and 8 expressions can be detected. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image among a group of snapshots

    Auto Tracking

    Yes

    SMD

    Yes

    Video

    Video Compression

    Smart H.265+;H.265;Smart H.264+;H.264;H.264B;

    H.264H;MJPEG(Sub Stream)

    Streaming Capability

    3 streams

    Resolution

    4M (2560 × 1440); 3M (2048 × 1536); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

    Video Frame Rate

    Main stream: 4M/3M/1080p/1.3M/720p (1–25/30 fps)
    Sub stream 1: D1/VGA/CIF (1–25/30 fps)
    Sub stream 2: 1080p/1.3M/720p (1–25/30 fps)

    Bit Rate Control

    CBR/VBR

    Video Bit Rate

    H264: 96 Kbps–14,848 Kbps
    H265: 38 Kbps–8,960 Kbps

    Day/Night

    Auto (ICR)/Color/B/W

    BLC

    Yes

    WDR

    140 dB

    HLC

    Yes

    White Balance

    Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp

    Gain Control

    Auto; manual

    Noise Reduction

    2D NR; 3D NR

    Motion Detection

    Yes

    Region of Interest (RoI)

    Yes

    Defog

    Electronic

    Digital Zoom

    16×

    Image Rotation

    180°

    Privacy Masking

    Up to 24 areas can be set, with up to 8 areas in the same view;
    multiple colors available

    S/N Ratio

    ≥ 55 dB

    Audio

    Audio Compression

    PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723

    Network

    Network Port

    RJ-45 (10/100 Base-T)

    Network Protocol

    HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;802.1x;SSL;Qos;FTP;UPnP;ICMP;SNMP;IGMP;ARP;RTCP;RTP;PPPoE;RTMP;Bonjour;NFS

    Interoperability

    ONVIF(Profile S&G&T);CGI;SDK

    Streaming Method

    Unicast/Multicast

    User/Host

    20 (total bandwidth: 64 M)

    Storage

    Micro SD card (512 GB); FTP/SFTP; NAS

    Browser

    IE 9 and later versions
    Chrome 42 and later versions
    Firefox 50 and later versions
    Safari 10 and later versions

    Mobile Client

    iOS;Android

    Port

    RS-485

    1 (baud rate: 1,200 bps–9,600 bps)

    Audio Input

    1 channel (LINE IN, bare wire)

    Audio Output

    1 channel (LINE OUT,bare wire)

    Alarm Linkage

    Capture; preset; tour; pattern; recording; alarm digital input; audio; send email

    Alarm Event

    Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card status detection; memory space detection; power exception detection

    Alarm I/O

    7/2

    Audio I/O

    1/1

    Power

    Power Supply

    36 VDC/2.23 A ± 25%; Hi-PoE

    Power Consumption

    Basic: 17 W
    Max.: 30 W (illuminator + heater + PTZ)

    Environment

    Operating Temperature

    –40 °C to +70 °C (–40 °F to +158 °F)

    Operating Humidity

    ≤ 95%

    Protection

    IP67; IK10; TVS 8000 V lightning proof; surge protection; voltage transient protection

    Structure

    Product Dimensions

    415.9 mm × Φ262.0 mm (16.37" × Φ10.31")

    Net Weight

    8.5 kg (18.74 lb)

    Gross Weight

    13.1 kg (28.88 lb)
