Basic

Device Type

AP

Hardware

WAN Port

1× RJ-45 10/100/1000/2500 Mbps (PoE In)

LAN Port

1 × RJ-45 10/100/1000 Mbps

Power Supply

802.3 af PoE
802.3 at PoE

Antenna Type

Omnidirectional

Built-in Antenna

2.4 GHz: 2 × 3.5 dBi
5 GHz: 2 × 6 dBi

Memory

DDR: 512 MB

Indicator Light

1 × PWR
1 × SYS
4 × WAN
1 × 2.4G
1 × 5G

External Port

1 × Console

Performance

Wireless Standard

2.4 GHz: IEEE 802.11b/g/n/ax
5 GHz: IEEE 802.11a/n/ac/ax

Wireless Transmission Rate

2.4 GHz: 574 Mbps
5 GHz: 2402 Mbps

Operating Frequency

2.4 GHz–2.484 GHz
5.150 GHz–5.850 GHz

Channel Width

2.4 GHz: 20/40/80 MHz
5 GHz: 20/40/80/160 MHz

2.4 GHz Antenna Gain

3.5 dBi

5 GHz Antenna Gain

6 dBi

Max. Output Power

CE EIRP:
≤20 dBm@2400-2483.5 MHz
≤23 dBm@5150-5250 MHz
≤23 dBm@5250-5350 MHz
≤27 dBm@5470-5725 MHz
≤14 dBm@5725-5850 MHz

2.4 GHz Max Power Output

26 dBm

5 GHz Max Power Output

25 dBm

Receiver Sensitivity

11ac VHT20_MCS0:-88 dBm
11ac VHT20_MCS8:-67 dBm
11ac VHT40_MCS0:-88 dBm
11ac VHT40_MCS7:-64 dBm
11ax HE20_MCS0:-88 dBm
11ax HE20_MCS11:-61 dBm
11ax HE40_MCS0:-88 dBm
11ax HE40_MCS11:-58 dBm

Max. Transmission Distance

100 m (328.08 ft)

Optimal Transmission Distance

80 m (262.47 ft)

SSID Number

2.4 GHz: 4
5 GHz: 4

Connected Wireless Terminals

2.4 GHz: 64
5 GHz: 64

PoE

PoE In: 802.3af/at (15 W/30 W)

Function

Equipment Management

Web; platform; app

Network Protocol

TCP/IP;IPv4;UDP;NTP;DHCP;DNS;QoS;ICMP;ARP;IP Filter;TCP;SMB;NFS;MQTT;802.11k;802.11v;802.11e;WMM;IGMP V3

Operating Mode

FIT AP
FAT AP
Gateway mode

Encryption Mode

No Encryption
WPA/WPA2PSK; WPA2/WPA3PSK

Firmware Update

Web update

Security Mechanism

IP address filtering; MAC address filtering

OFDMA

Yes

MU-MIMO

2 × 2

Beamforming

Yes

TWT

No

DHCP

Yes (under gateway mode)

NAT

Yes (under gateway mode)

QoS

Yes

DDNS

No

Wireless Repeater

No

MESH

No

Software

Device Management: setup wizard; network connection method; back up/restore configuration; restore factory defaults; schedule restart; system logs; change password; firmware upgrade; system time; fat/fit mode self-adaptation; cloud platform configuration
AP Management: SSID configuration; VLAN ID configuration; frequency configuration; country/region configuration; 5G-Prior access configuration; scheduled Wi-Fi shutdown
Client Management: MAC ACL; user isolation; limit users that can access

General

Power Consumption

Full load: 16 W
Idling: 5.6 W

Operating Temperature

–20 °C to +55 °C (–4 °F to +131 °F)

Storage Temperature

–40 °C to +70 °C (-40 °F to +158 °F)

Operating Humidity

5%–95% (RH), non-condensing

Net Weight

1.06 kg (2.34 lb)

Gross Weight

1.62 kg (3.57 lb)

Product Dimensions

304 mm × 230 mm × 107 mm (11.97" × 9.06" × 4.01") (L × W × H)

Packaging Dimensions

380 mm × 230 mm × 107 mm (14.96" × 9.06" × 4.01") (L × W × H)

Protection

IP65

Statics Protection

Air discharge: 8 kV
Contact discharge: 6 kV

Lightning Protection

Common mode: 4 kV
Differential mode: 2 kV

Installation

Pole mount (recommended)
Wall mount (might affect signal coverage)

Certifications

CE

Packing List

1 × Device
1 × Pole-mounting Kit
1 × Wall-mounting Kit
1 × Waterproof Kit
1 × PoE Adapter
1 × Quick Start Guide
1 × Legal and Regulatory Information
1 × Bracket
