Thermal

Detector Type

Vanadium oxide uncooled focal plane detector

Effective Pixels

400 (H) × 300 (V)

Pixel Pitch

12 μm

Spectral Range

8 μm–14 μm

Sensitivity (NETD)

≤35 mK (@f/1.0)

Field of View

9 mm: H:30.2°; V: 22.6°

13 mm: H:20.92°; V: 15.77°

19 mm: H:14.4°; V: 10.82°

25 mm: H:10.97°; V: 8.24°

Thermal Focus
Control

Fixed-focal

Close Focus
Distance

9 mm: 1.8 m

13 mm: 4 m

19 mm: 8 m

25 mm: 15 m

Digital Detail
Enhancement
(DDE)

Yes

Digital Zoom

19 levels

Thermal AGC

Auto/Manual

Thermal Noise
Reduction

2D NR/3D NR

Image Flip

180°; Mirror

Color Palettes

18 (white hot/black hot/fusion/rainbow/golden autumn/midday/iron red/amber/jade/sunset/icefire/painting/pomegranate/emerald /spring/summer/autumn/winter)

Visible

Image Sensor

1/2.7" CMOS

Max. Resolution

2688 (H) × 1520 (V)

Pixel

4 MP

Horizontal
Definition

≥1100 TVL

Min. Illumination

Color: 0.01 lux
Black & white: 0.001 lux
0 lux (white light on)

Visible AGC

Auto/Manual

Visible Noise
Reduction

2D NR/3D NR

S/N Ratio

>55 dB

White Balance

Auto; manual; indoor; outdoor; tracking;
sodium lamp; street lamp; natural

Defog

Electronic defog

Electronic Shutter
Speed

1 s–1/30,000 s (auto/manual)

BLC

Yes

WDR

Yes

HLC

Yes

Day/Night

Auto (ICR); Color; B/W

Iris Control

Fixed

Image Flip

180°; Mirror

Exposure
Compensation

Yes

Visible Focus
Control

Fixed-focal

Field of View

4 mm: H: 91.1°; V: 48.2°

6 mm: H: 56.1°; V: 30.1°

8 mm: H: 41.3°; V: 23.1°

12 mm: H: 37.3°; V: 21.4°

Close Focus
Distance

4 mm: 2 m

6 mm: 2.5 m

8 mm: 8 m

12 mm: 7.4 m

Aperture

F1.6

Illuminator On/Off Control

Auto; manual

Illumination
Distance

30 m

Audio and Video

Video Compression

H.265; H.264M; H.264H; H.264B

Resolution

Thermal:

Main stream: 1280 × 1024; 1280 × 960; 1280 × 720;

400 × 300; 1280 × 960 (default)

Sub stream: 640 × 512; 640 × 480;
400 × 300;

400 × 300 (default)

Visible:

Main stream: 2688 × 1520; 2560 × 1440; 1920 × 1080; 1280 × 720); 704 × 576;
2560 × 1440 (default)

Sub stream: 704 × 576; 352 × 288;
704 × 576 (default)

Video Frame Rate

Thermal (50 Hz):

Main stream: 1 fps–25 fps, 25 fps by default

Sub stream: 1 fps–25 fps, 15 fps by default

Visible (50 Hz):

Main stream: 1 fps–25 fps, 25 fps by default

Sub stream: 1 fps–25 fps, 15 fps by default

Thermal (60 Hz):

Main stream: 1 fps–30 fps, 30 fps by default

Sub stream: 1 fps–30 fps, 15 fps by default

Visible (60 Hz):

Main stream: 1 fps–30 fps, 30 fps by default

Sub stream: 1 fps–30 fps, 15 fps by default

Audio Compression

G.711a; G.711 mu

Image Encoding Format

JPEG

Function

Two-way Audio

Yes

Sound and Light
Alarm

Local audio and white light alarm prompts

Network Protocol

IPv4/IPv6; HTTP; HTTPS; 802.1x; QoS; FTP;
SMTP; UPnP; SNMP; DNS; DDNS; NTP; RTSP;
RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE

Region of Interest (RoI)

Yes (customizable)

Storage

FTP; Micro SD card (512 GB, hot swapping)

Interoperability

ONVIF; CGI; DaHua SDK

Browser

IE; Firefox; Chrome; Safari

User Management

Up to 20 users; supports multi-level user
permissions (2 levels): management group and user group

Malfunction
Detection

Network disconnection detection; IP conflict
detection;
memory card state detection; memory space
detection

Fusion Mode

Yes. Off by default

PIP

Yes

Intelligence

Heat Detection

Yes

Cold/Hot Spot
Trace

Yes

Perimeter
Protection

Yes. Supports tripwire and intrusion.

Target Distinction

Human/Vehicle Classification

Smoke Detection

Yes

Port

Analog Output

1 × CVBS output; BNC port

Network Port

1 × RJ-45 (10/100 Base-T)

Alarm Input

2

Alarm Output

2

Audio Input

1

Audio Output

1

RS-485

1

Power

Power Supply

12 VDC ± 20%, PoE (802.3af), ePoE

Power
Consumption

Basic: 4.68 W (12 VDC); 5.4 W (PoE)

Max: 11.88 W (12 VDC); 12.8 W (PoE)

ePoE

Yes

Environment

Operating
Temperature

–30 °C to +70 °C (–22 °F to +158 °F)

Operating Humidity

≤95%

Storage
Temperature

–40 °C to +70 °C (–40 °F to +158 °F)

Physical Characteristics

Protection

IP67

Reliability

Surge protection: 6 kV
Air discharge: 15 kV
Contact discharge: 8 kV

Structure

Product
Dimensions

300.9 mm × 130.2 mm × 120.1 mm

Packaging
Dimensions

365 mm × 175 mm × 176 mm

Net Weight

≤1.4 kg

Gross Weight

≤1.9 kg

Lens

Included

Certification

Certifications

CE/FCC

Heat Detection Distance

Focal Lenght

Max. Distance

9 mm

86 m

13 mm

141 m

19 mm

220 m

25 mm

280 m

Note:

The table displays the measured distances obtained from
using the target size

0.2 m × 0.2 m for testing in an environment where the temperature is 23 °C and the relative humidity is below 60%.

The table is for reference only. The distances within it are
subject to actual conditions including atmospheric
conditions, target size, the installation site, and more.

Perimeter Protection Distance (IVS Distance)

Focal Lenght

Distance (Vehicle)

Distance (Human)

9 mm

63 m

189 m

13 mm

91 m

273 m

19 mm

133 m

399 m

25 mm

175 m

525 m
