Camera

Image Sensor

1/1.8" CMOS

Pixel

4 MP

Max. Resolution

2688 (H) × 1520 (V)

ROM

8 GB

RAM

4 GB

Electronic Shutter Speed

1/1 s–1/100,000 s

Scanning System

Progressive

Min. Illumination

0.001 lux@F1.4 (Color)

0.0001 lux@F1.4 (B/W)

0 lux (IR light on)

Illumination Distance

50 m (164.04 ft) (Warm light); 600 m (1968.50 ft) (Laser)

Illuminator On/Off Control

Zoom Prio; Manual; Auto; Off

Illuminator Number

4 (IR light); 1 (Warm light); 8 (Laser)

Wiper

Smart wiper

Lens

Focal Length

6.0 mm–252 mm

Max. Aperture

F1.4–F4.8

Field of View

H: 61.4°–2.3°; V: 36°–1.3°; D: 68.2°–2.6°

Optical Zoom

42×

Focus Control

Auto; Semi-auto; Manual

Close Focus Distance

0.5 m–2 m (1.64 ft–6.56 ft)

Iris Control

Auto/Manual/Iris Prio

DORI Distance

Lens

Detect

Observe

Recognize

Identify

W

82.7 m

( 271.52 ft)

32.6 m

( 107.25 ft)

16.5 m

( 54.30 ft)

8.2 m

( 27.15 ft)

T

3475.8 m

( 11403.75 ft)

1372.97 m

( 4504.48 ft)

695.1 m

( 2280.75 ft)

347.5 m

( 1140.37 ft)

PTZ

Pan/Tilt Range

Pan: 0° to 360° endless, smart pan-tilt correction; Tilt: –20° to +90°, auto flip 180°, smart pan-tilt correction

Manual Control Speed

Pan: 0.1°/s–240°/s; Tilt: 0.1°/s–100°/s

Preset Speed

Pan: 240°/s; Tilt: 100°/s

Preset

300

Tour

8 (up to 32 presets per tour)

Pattern

5

Scan

5

Power-off Memory

Yes

Idle Motion

Preset;Pattern;Tour;Scan

PTZ Protocol

DH-SD

Pelco-P/D (auto recognition)

Smart pan-tilt correction

YES

Intelligence

Video Metadata

Supports detection of motor vehicles, non-motor vehicles, faces and human bodies, optimization, capturing pictures, and uploading high-quality face snapshots. It extracts attributes from motor vehicles and non-motors, detecting up to 10 attributes for motor vehicles and 8 for non-motor vehicles. It also extracts attributes from human faces and bodies, detecting up to 6 attributes for faces, and 8 for bodies.

IVS (Perimeter Protection)

Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human and vehicle alarm classification; detail camera linkage for positioning and tracking when multiple rules are triggered; cascaded video metadata; linkage tracking; privacy protection

Face Recognition

Supports face detection, optimization, capturing pictures, uploading high-quality face snapshots and enhancing face images. Attribute extraction is also supported, where 6 attributes and 8 expressions can be detected. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. It supports up to 5 face databases, where people can be added one by one or in batches. The face similarity can also be set, and faces can be compared against 10,000 faces

Smart Tracking

AutoTracking 3.0

AcuPick

Uses deep learning algorithms and works with backend devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets

Privacy Protection

For public scenes, mosaics can be used in real time to block detected human faces or body parts on the monitoring screen while people are moving to protect the privacy of special groups.

Video

Video Compression

Smart H.265+;H.265;Smart H.264+;H.264;H.264B;H.264H;MJPEG(Sub Stream 1)

Streaming Capability

3 streams

Resolution

4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Video Frame Rate

Main stream: 4M/1080p/1.3M/720p@(1–50/60 fps)

Sub stream 1: D1/VGA/CIF@(1–25/30 fps)

Sub stream 2: 1080p/1.3M/720p/CIF@(1–25/30 fps)

Bit Rate Control

CBR/VBR

Video Bit Rate

H264: 96 kbps–15616 kbps

H265: 38 kbps–9472 kbps

Day/Night

Auto/Color/B/W/Electronic

BLC

Yes

WDR

140 dB

HLC

Yes

White Balance

Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp

Gain Control

Auto; Manual; Gain Prio

Noise Reduction

2D NR; 3D NR

Motion Detection

Yes

Region of Interest (RoI)

Yes

Image Stabilization

Gyroscope EIS

Defog

Optical

Digital Zoom

16×

Image Rotation

180°

Privacy Masking

Up to 24 areas can be set, with up to 8 areas in the same view; color block and mosaic selectable

S/N Ratio

≥ 55 dB

Audio

Audio Compression

PCM; G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G722.1; G729; G723

Network

Network Port

RJ-45 (10/100 Base-T)

Network Protocol

HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;802.1x;SSL;QoS;FTP;UPnP;ICMP;SNMP;IGMP;ARP;RTCP;RTP;PPPoE;RTMP;Bonjour;NFS

Interoperability

ONVIF (Profile S & Profile G & Profile T);CGI;SDK

Streaming Method

Unicast/Multicast

User/Host

20 (total bandwidth: 64 M)

Storage

Micro SD card (512 GB); FTP; NAS

Browser

IE 9 and later versions

Chrome 41 and later versions

Firefox 50 and later versions

Safari 10 and later versions

Management Software

DMSS;NVR;DSS Pro

Mobile Client

iOS;Android

Certification

Certifications

CE: EN55035; EN IEC61000-3-2; EN55032; EN60950; EN62368-1

Port

Analog Output

1 channel (CVBS output, BNC)

RS-485

1 (baud rate: 1200 bps–9600 bps)

Audio Input

1 channel (LINE IN, bare wire)

Audio Output

1 channel (LINE OUT,bare wire)

Alarm Input

7 (on-off value input: 0–5 VDC)

Alarm Output

2 channels

Alarm Linkage

Capture; preset; tour; pattern; recording; alarm digital output; send email; audio

Alarm Event

Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection

Power

Power Supply

36 VDC; 2.23 A (±25%)

PoE (802.3bt)

Power Consumption

Basic: 16 W

Max. (Illuminator + PTZ operation + Wiper operation): 41 W

Power Adapter

Included

Environment

Operating Temperature

–40 °C to +70 °C (–40 °F to +158 °F)

Operating Humidity

≤ 95%

Protection

IP67;TVS 6000 V lightning proof; surge protection; voltage transient protection

Anti-corrosion Level

Basic Protection

*The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection.

Structure

Product Dimensions

262 mm × 262 mm × 442 mm (10.31" × 10.31" × 17.40") (L × W × H)

Net Weight

10.38 kg (22.88 lb)

Gross Weight

13.83 kg (30.49 lb)
