LM27-EM341A new-products

Dahua 27" QHD 1152 Zones QD-MiniLED Gaming Monitor

> Mini-LED – Improves HDR with full-array local dimming and 1,152 zones for deeper blacks and brighter highlights.

> 2560×1440 resolution produces clearer and more vivid pictures.

> Experience stunning visuals with HDR1000, delivering ultra-bright highlights, deep blacks, and lifelike contrast for truly immersive viewing.

> Images are delivered in excellent color accuracy with 99% DCI-P3 color coverage for you to see your work in vibrant, consistent colors.

> With a high refresh rate that reaches up to 275Hz, images and videos are rendered with smoothness and fluidity.

> 1ms Response Time – Eliminates screen tearing and choppy frame rates.

> Adjust the rotating lift base to the ideal working position for greater comfort.


  • Specifications
  • Accessories
  • Download
  • selector-pcimg

    Product Selector

    Display

    Model

    DHI-LM27-EM341A

    LCD Technology

    IPS

    Backlight

    DLED

    Local Dimming

    1152 zones

    Screen Size

    27 inch

    Aspect Ratio

    16:9

    Viewing Size

    596.74 (H) × 335.66 (V) mm

    Screen-to-Body Ratio

    ≥90%

    Viewing Angle

    178° (H)/178° (V)

    Display Mode

    Horizontal

    Pixel Pitch

    0.2331 mm × 0.2331 mm (0.0092" × 0.0092")

    Pixels Per Inch

    108.79

    Resolution

    2560 (H) × 1440 (V)

    Refresh Rate

    240 Hz (overclocking: 275 Hz)

    Display Color

    1.07B (8 bits + FRC)

    Color Gamut

    99% DCI-P3

    Color Accuracy

    ΔE<2

    Brightness

    SDR : 450 cd/m² (typ.)

    HDR : 1000 cd/m² (typ.)

    Contrast Ratio

    1000:1

    Response Time

    OD 1 ms

    Lifespan

    30,000 hrs

    Operation Hours

    7 × 16 H

    Surface Treatment

    Haze 25%，3H

    Flicker-free Technology

    Yes

    Low Blue Light

    Software blue light protection

    Function

    HDR

    HDR 1000

    Device Ports

    Input Port

    2 × HDMI 2.1 TMDS (2560 × 1440@144 Hz), 1 × DP 1.4 (2560 × 1440@275 Hz)

    Output Port

    1 × Audio out

    Power & Environmental Conditions

    Power Supply

    19 VDC, 7.89 A

    Power Type

    power adapter

    Power Consumption

    60 W (basic), 72 W (typ.), 98 W (max)

    Standby Power Consumption

    <0.5 W

    Operating Temperature

    0 °C to +40 °C (+32 °F to +104 °F)

    Operating Humidity

    10% - 85% (RH)

    Storage Temperature

    -20 °C to +60 °C (-4 °F to +140 °F)

    Storage Humidity

    5% – 90% (RH)

    General

    Inclined Angle

    -5° / +20°

    Left and Right Rotation Angle

    -25° / +25°

    Vertical Rotation Angle

    -90° / +90°, requires 20° backward tilt before rotation

    Height Adjustment

    120 mm (4.72")

    Product Dimensions

    614.2 mm × 364.0 mm × 66.0 mm (24.18" × 14.33" × 2.60") (W × H × D), without wall-mount bracket

    Package Size

    886 mm × 449 mm × 215 mm (34.88" × 17.68" × 8.46") (W × H × D)

    Frame Width

    U/L/R/D: 0.07" / 0.09" / 0.09" / 0.72"

    Net Weight

    6.6 kg (14.55 lb)

    Gross Weight

    8.1 kg (17.86 lb)

    Casing Color

    Black

    Control Mode

    Five-button

    RGB Light Effect

    Severn colors

    Status Indicator Light

    Yes

    Wall Mount VESA

    100 mm × 100 mm (3.94" × 3.94")

    Accessory

    Power Adapter, Bracket, Base, DP Cable, User Manual (QR Code), Legal and Regulatory Information, Energy Label

    Optional Accessory

    Wall mount

    Certification

    Certifications

    CE EMC, CE LVD, CE ERP
