Capacity

Capacity

1500 VA, 900 W

Input

Input Voltage

170–280 VAC

Input Current

7.2 A

Rated Input Frequency

50/60 Hz

Power Factor

≥0.6

Output

Output Voltage

230 VAC by default

Output Current

6.9 A

Output Power

1500 VA, 900 W

Output Frequency

50 Hz ± 0.1 Hz

Switch Time

Typical 4 ms–8 ms

Output Wave

AC Mode: Pure sine wave;
Battery Mode: Simulated sine wave

Battery

Built-in Battery

Yes

Battery Type

Lead-acid battery

Qty.of Battery

2 × 7Ah

Charging Current

1 A

Limited Charge Voltage

13.7 V/pcs

Charging Time

4H–6H to 90%

Max Travel Time on Full Battery

3 min

Indicators

Status Indicator Light

Battery mode: Red light flashes once every 10 seconds
Mains power mode: Green light solid on
Fault mode: Red light solid on

Alarm

Alarm Indicator

Battery Mode: Beeps once every 10 seconds
Low Battery: Beeps once every second
Overload: Beeps once every 0.5 seconds and continues to beep when there is a fault

Protection

Types of Protection

Protects against overload, battery overcharge, and over-discharge

Overload Capacity

30 sec

Plugs and Sockets

Input Plug

European standard

Input Cable Length

1.2 m (3.94 ft)

Socket Standard

European standard

Number of Output Sockets

2

Structure

Product Dimensions

370 mm × 138 mm × 165 mm (14.57" × 5.43" × 6.50") (L × W × H)

Packaging Dimensions

470 mm × 195 mm × 255 mm (18.50" × 7.68" × 10.04") (L × W × H)

Casing Material

Plastic

Appearance Color

Black

Net Weight

11.4 kg (25.13 lb)

Gross Weight

11.8 kg (26.02 lb)

Environment

Operating Temperature

0 °C to +40 °C (+32 °F to +104 °F)

Operating Humidity

0%–90%, non-condensing

Storage Temperature

–15 °C to +55 °C (+5 °F to +131 °F)

Storage Humidity

0%–90%, non-condensing

Certifications

Certifications

CE
