System

Button

Battery /LED Button
Power Button

LED

1 × 35 lm 5 mm LED light
1 system indicator
1 Wi-Fi indicator

IPC Test

Camera Access

ONVIF and Dahua private protocol

Resolution

1 MP; 1.3 MP; 2 MP; 3 MP; 4 MP; 5 MP; 6 MP; 8 MP

Initialization

Yes


Live video, zoom, and decoding through H.264 and H.265.

Function Control

Supports changing the IPC resolution, IP address and device password. You can also control the IPC and restore it to its default factory settings.

Wireless

Wi-Fi Hotspot

Yes

Network

Wi-Fi Standard

IEEE 802.11a/b/g/n/ac

Frequency Range

2.4 GHz–2.4835 GHz

Transmitter Power (EIRP)

≤ 16.5 dBm@2,400–2,483.5 MHz;
≤ 16 dBm@5,150–5,250 MHz;
≤ 16 dBm@5,250–5,350 MHz;
≤ 16 dBm@5,725–5,850 MHz

Others

Power Supply for Camera

12 VDC, 1 A; PoE 802.3af, power (max): 16 W

Port

Power

1 × Type C charging port
1 × 12 VDC port, DC current (max): 1 A

USB

1 × USB port. DC current (max): 2 A, 5 V

Network Port

4 × 100 Mbps Ethernet ports
1 × PoE output port that can be used as a 100 Mbps Ethernet port. The max power is 16 W

Power Supply

Power Supply

Type C

Battery

Built-in 3.7 V polymer lithium battery with a capacity of 7800 mAh. It can work for up to 22 hours on a full charge, without any external power supply.

Protection

Surge Protection Grade

Common mode: ±2 kV;
Differential mode: ±1 kV

Statics Protection

Air discharge: 8 kV;
Contact discharge: 6 kV

Structure

Appearance Color

Black; Includes a yellow leather case.

Product Dimensions

130 mm × 95 mm × 37 mm (5.12" × 3.74" × 1.46") (L × W × H)

Packaging Dimensions

145 mm × 105 mm × 65 mm (5.71" × 4.13" × 2.56") (L × W × H)

Packaging Method

1 pcs in 1 carton, and 30 cartons in 1 package

Net Weight

0.332 kg (0.73 lb)

Gross Weight

0.385 kg (0.85 lb)

Environment

Operating Temperature

–10 °C to +50 °C (+14 °F to +122 °F)

Operating Humidity

30%–90% (RH)

Storage Temperature

–20 °C to +70 °C (–4 °F to +158 °F)

Storage Humidity

30%–90% (RH)

Certifications

Certifications

CE Related Standards:
Article 3.1a): EN IEC 62386-1:2024+A11:2024
EN 50566:2017+A1:2023
EN IEC/IEEE 62209-1528:2021
Article 3.1b): ETSI EN 301489-1 V2.2.3 (2019-11)
ETSI EN 301489-17 V3.3.1 (2024-09)
EN 55032:2015+A1:2020+A11:2020
EN 55035:2017+A11:2020
Article 3.2): ETSI EN 300328 V2.2.2 (2019-07)
FCC Related Standards: FCC Part 15 Subpart B
