Display

Model

DHI-LM22-C201P

LCD Technology

IPS

Backlight

ELED

Screen Size

21.5 inch

Aspect Ratio

16:9

Resolution

1920 (H) × 1080 (V)

Refresh Rate

100 Hz

Display Color

8 bit

Color Gamut

72% NTSC

Brightness

250 cd/m² (typ.)

Contrast Ratio

1000: 1

Viewing Angle

178° (H) / 178° (V)

Display Mode

Horizontal

Response Time

OD 5 ms

Lifespan

30,000 hrs

Surface Treatment

Haze 25%, 3H

Device Ports

Input Port

1 × HDMI 1.4 (1920 × 1080@100 Hz), 1 × VGA (1920 × 1080@60 Hz)

Output Port

1 × Audio out

Power & Environmental Conditions

Power Supply

12 VDC, 2 A

Power Type

power adapter

Power Consumption

15 W (basic), 15 W (typ.), 24 W (max)

Standby Power Consumption

< 0.5 W

Operating Temperature

0 °C to +40 °C (+32 °F to +104 °F)

Operating Humidity

10%–85% (RH)

Storage Temperature

–10 °C to +50 °C (+14 °F to +122 °F)

Storage Humidity

5%–95% (RH)

General

Inclined Angle

-5° ± 2° / 15° ± 2°

Product Dimensions

492.8 mm × 368.5 mm × 222.7 mm (19.40" × 14.51" × 8.77") (W × H × D), with stand

Package Size

561 mm × 429 mm × 152 mm (22.09" × 16.89" × 5.98") (W × H × D)

Frame Width

U/L/R/D: 2 mm/2 mm/2 mm/15 mm

Net Weight

2.64 kg (5.82 lb)

Gross Weight

4.14 kg (9.13 lb)

Accessory

Power adapter, HDMI cable, user's manual, legal and regulatory information etc.

Certification

Certifications

CE EMC, CE LVD, CE ERP
