Model

Model

DHI-AC22-I320ZB

Display

Screen Size

21.45"

Panel type

IPS

Aspect Ratio

16:9

Resolution

1920x1080

Backlight

LED

Brightness/Luminance

250 cd/㎡

Contrast

1000:1

Display Color

16.7M(8bit)

Viewing Angle(H/V)

178°(H)/178°(V)

Response time(typ.)

14ms

Refresh Rate

60Hz

Signals

Front (side) interface

USB2.0x2, Earphone x1, TYPECx1, SD card slot x1

Bottom interface

HDMI OUTX1 COMK1USB-A3.0(5GB)x2 USB-43.2(10GB)x2RJ45x1,AUDIO OUTx1,MIC INx1(Universal audio jack)

Speaker

2Wx2

General

Power Supply

19V 6.32A

Consumption (Standard)

120W

Consumption (Standby)

≤0.5W

Net Weight

4 kg

Stand

NA

Wall Mount

100x100mm (4.0"x4.0")

Dimension with stand (W×H×D)

493x285x34mm(19.4“x11.2”x1.3”)

Package

551x195x436mm(21.7''x7.7''x17.2'')

Work Environment

Temperature

0℃~40℃ (32°F~104°F)

Humidity

10%~85%

Accessory

Standard

base, power cord/screw, adapter, manual,wireless mouse and keyboard(no bottery)

Certifications

Certifications

CE

Internal Player

MainBoard

JW B660I Thin Mini-ITX

Chip

Intel B660

Cpu

InteI i3 12100

Memory

8G DDR4

Hard disk

256G SSD

Graphics card

Intel integrated graphics

WIFI/ Bluetooth

The Tel2.4ghz /5GHz/802.11a/b/g/n/ac 4.2 standard supports

both IPv6 and 6LoWPAN

LAN

Gigabit Ethernet front-end ports

Video camera

Built-in 500W camera + double label press window type

System

UEFI

Other

The right side of the bottom brightness adjustment, one key screen, one key mute, hand sweep lamp function
