VTO1210B-X-S1
Apartment Outdoor Station
> HD CMOS camera
> Tempered glass panel, IP65(Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)
> Night vision & Voice indication
> Local card openning
> Video & Audio messaging
> Flush mounted
Technical Specification
Model
VTO1210B-X-S1
System
Main Processor
Embedded Micro Processor
Operation System
Embedded LINUX OS
Video
Video Compression
H.264
Image Sensor
1/3" 1.3MP CMOS
Lens
4mm
Angle of View
H:71°, V:52°, D:92°
Day/Night
Color Image
Audio
Audio Compression
G.711
Audio Input
Omnidirectional Mic
Audio Output
Built-in Speaker
Bidirectional Talk
Support Dual-way Bidirectional talk
Display
LCD Screen
3" STN 128x64
Operation Mode
Keypad
Touch Button
Reader
Mifare Card
Approaching Induction
Body approaching
0.6m
Interface
Door Control
1
Alarm In
2(1ch unlock button, 1ch feedback)
RS485
1
Network
Ethernet
10M/100Mbps
Network Protocol
TCP/IP
General
Ingress Protection
IP65
Tamper Switch
1
Installation
Flush
Material
Tempered glass
Power
DC 12V
Power Consumption
Work ≤10W
Working Temperature
﹣30°C to +60°C
Relative Humidity
10%RH–90%RH
Dimensions
150.0mm×408.0mm×46.4mm
Weight
1.6kg
