DHI-LM22-L200V
21.45'' FHD LED Monitor (Project Series)
· Suitable for continuous 24/7 operation .
· 3 sides narrow bezel design, elegant appearance, ultra-light base .
· 1ms fast response time for no motion blur, judder or ghosting.
· 178°/178° extra-wide viewing angle for overall viewing performance.
· Support multiple signal inputs including HDMI and VGA .
· Low energy consumption, long service life.
Model
Model
DHI-LM22-L200V Display
Screen Size
21.45"
Panel type
IPS
Aspect Ratio
16:9
Resolution
1920x1080 (FHD)
Backlight
E-LED
Brightness(typ)
300 cd/㎡
Contrast Ratio
1000:1
Color Gamut
72% NTSC
Display Colorbbit
8 bit Viewing Angle(H/V)
178°(H)/178°(V)
Response time(typ)
1ms
Refresh Rate (max)
100Hz
Signals
Input
HDMI×1,VGA×1
Output
NA
Power Supply
12V DC, 2A
Power Consumption (Standard)
22W
Power Consumption (Standby)
< 0.5W
Net Weight (kg)
2.3kg (5.07lb) Gross Weight (kg)
3.4kg (7.5lb) VESA
YES
Tilt
-5°~15° Product Dimension without Base(W×H×D)
493.1x384.2x190mm (19.4“x15.1”x7.5”)
Work Environment
Temperature
0℃~40℃ (32°F~104°F) Humidity
10%~90%
Accessory
Standard
HDMI cable, Power Adapter, base
Optional
Hanging bracket
