DHI-LM22-L200V

21.45'' FHD LED Monitor (Project Series)

· Suitable for continuous 24/7 operation .

· 3 sides narrow bezel design, elegant appearance, ultra-light base .

· 1ms fast response time for no motion blur, judder or ghosting.

· 178°/178° extra-wide viewing angle for overall viewing performance.

· Support multiple signal inputs including HDMI and VGA .

· Low energy consumption, long service life.





  • Specifications
  • Accessories
  • Download
  • selector-pcimg

    Product Selector

    Model

    Model

    DHI-LM22-L200V

    Display

    Screen Size

    21.45"

    Panel type

    IPS

    Aspect Ratio

    16:9

    Resolution

    1920x1080 (FHD)

    Backlight

    E-LED

    Brightness(typ)

    300 cd/㎡

    Contrast Ratio

    1000:1

    Color Gamut

    72% NTSC

    Display Colorbbit

    		8 bit

    Viewing Angle(H/V)

    178°(H)/178°(V)

    Response time(typ)

    1ms

    Refresh Rate (max)

    100Hz

    Signals

    Input

    HDMI×1,VGA×1

    Output

    NA

    Power Supply

    12V DC, 2A

    Power Consumption (Standard)

    22W

    Power Consumption (Standby)

    < 0.5W

    Net Weight (kg)

    2.3kg (5.07lb)

    Gross Weight (kg)

    3.4kg (7.5lb)

    VESA

    YES

    Tilt

    -5°~15°

    Product Dimension without Base(W×H×D)

    493.1x384.2x190mm (19.4“x15.1”x7.5”)

    Work Environment

    Temperature

    0℃~40℃ (32°F~104°F)

    Humidity

    10%~90%

    Accessory

    Standard

    HDMI cable, Power Adapter, base

    Optional

    Hanging bracket
