Technical Specification

Communication

LoRa

RF Frequency

470 MHz-510 MHz

Communication Distance

Free space: a maximum of 1500 metres

Ordinary walls: 3-5

Alarm Mode

Visual and audible alarm

Alarm Output

RF transmission

Operating Voltage

DC3V

Operating Current

Monitoring Current: ≤35uA

Alarm Current: ≤3mA

LED Instruction

Alarm: Red indicator flashes once every second

Fault: Yellow indicator flashes once every minute
Standby: Green indicator flashes once every minute

Battery Life

About 5 years

Battery

DC3V, 2400mAh

Operating Temperature

–10°C to +55°C (+14°F to +131°F)

Storage Temperature

–20°C to +60°C (-4°F to +140°F)

Operating Humidity

≤ 95% RH (no condensation)

Dimensions (with base)

106.5 mm × 157.5 mm × 56.7 mm (4.19" × 6.20" × 2.23")

Weight (with base and battery)

260 g (0.57 lb)

Installation

Wall Mount

Color

Red
