PFM801-4MP
1 Channel Passive HDCVI Balun with Power
>Power supply: Input voltage DC24-36V, can provide DC12V 8W(max) power supply to remote cameras, simplify engineering wiring.
>Transmission effect: Real-time transmission video, no delay, strong anti-interference.
>Transmission distance: 400m (max).
>Mainfunctions: Use single UTP (CAT-5E and CAT-6) real-time transmit 1-ch HD videosignal and 1-ch DC power.
>Protectionand anti-interference: Excellent anti-thunder, anti-static andanti-interference capabilities.
>Appearancestructure: ABS engineering plastics shell, small size, use RJ45 standardinterface connection mode.
>Transmission effect: Real-time transmission video, no delay, strong anti-interference.
>Transmission distance: 400m (max).
>Mainfunctions: Use single UTP (CAT-5E and CAT-6) real-time transmit 1-ch HD videosignal and 1-ch DC power.
>Protectionand anti-interference: Excellent anti-thunder, anti-static andanti-interference capabilities.
>Appearancestructure: ABS engineering plastics shell, small size, use RJ45 standardinterface connection mode.
Model PFM801-4MP Properties Transmission Signal 1 channel Transmission Distance HDCVI:
720P: max.400m(1312.34ft);
1080P: max. 250m(820.21ft);
4MP: max. 200m(656.17ft)Power Supply Input Voltage Distance Output Power DC24 0-100m DC12V 8W 100-200m DC12V 6W 200-300m DC12V 3W DC36 0-300m DC12V 8W Category Type UTP CAT5E/6 Video Transmission Properties Coaxial Video Connector BNC-M Connection Way RJ45 Compatible Format HDCVI/TVI/AHD/CVBS Resolution 720P/1080P/4MP Anti-interference >60db Protection ESD 1a contact discharge electricity level 3 1b air discharge electricity level 3 Per: IEC61000-4-2 Coaxial Cable Connector 2KV(common-code) Per: IEC61000-4-5 UTP Cable Connector 2KV(different-code), 4KV(common-code) Per: IEC61000-4-5 Impedance BNC Male 75 ohms UTP Cable 100 ohms Physical Properties Dimension(L*W*H) 72.6mm*42.5mm*24.5mm(2.86”x1.67”x0.96”) Shell ABS Color Black N.W. 66.4g(0.15lb)/57.4g(0.13lb) Stability MTBF >10000H Environmental Operating Temperature -10℃~+55℃(14℉~131℉) Storage Temperature -20℃~+70℃(-4℉~158℉) Humidity 0~95%(non-condensing)
