ARA46-N-W2(868)
Alarm Repeater Pro(Only compatible with ARC3800H series)
> Supports connecting to the Hub through Ethernet, Wi-Fi and RF. All communication channels can be connected simultaneously to enhance reliability.
> Supports frequency hopping and two-way communication to ensure stable and reliable communication with wireless peripherals.
> Supports cloud update. Remote update of alarm repeater pro can be performed on mobile app.
> Supports dual-system backup to automatically recover from update failure, and to ensure reliability during update.
> Supports offline linkage to enhance system security.
> Supports manually or automatically adding peripherals to alarm repeater pro.
> Supports forwarding images and audio data.
Port
Wireless Peripheral
128 wireless peripherals
Network Mode
Ethernet and Wi-Fi
Network Port
1 RJ-45, 10 Mbps/100 Mbps Ethernet port
Storage Battery
One built-in 4,750 mah rechargeable lithium battery
Function
Indicator Light
1 indicator for indicating pairing and working status
Button
Includes a reset button, power button and AP switch button
Remote Update
Cloud update
Low Battery Detection
Yes
Tamper
Yes
Pairing Mode
Auto/Manual
Technical
Operating Current
220 VAC, 100 mA (max)
220 VAC, 8.6 mA (standby)Wireless
Carrier Frequency
Airfly: 865-868.6 MHz
RF-HD (normal speed): 865-868 MHz
RF-HD (high speed): 2400-2483.5 MHzTransmitter Power (EIRP)
Limit 25 mW
Communication Mechanism
Two-way
Communication Distance
Airfly:2,000 m (6561.68 ft) RF-HD (normal speed):1,600 m (5249.34 ft) RF-HD (high speed):300 m (984.25 ft)
Encryption Mode
AES128
Frequency Hopping
Yes
General
Power Supply
100–240 VAC, 50/60 Hz
Standby Time
35 hours(only connected to the Hub through Airfly and normal speed RH-HD)
18 hours(connected to the Hub through Ethernet, Wi-Fi or high speed RF-HD)Power Consumption
22 W (max) 1.9 W (standby)
Operating Temperature
When battery is not charging: –10 °C to +50 °C (+14 °F to +122 °F) When battery is charging : 0 °C to +45 °C (+32°F to +113 °F)
Operating Humidity
10%–90% (RH)
Product Dimensions
174.8 mm × 174.8 mm × 38.3 mm (6.88" × 6.88" × 1.51") (L × W × H)
Net Weight
510 g (1.12 lb)
Gross Weight
860 g (1.90 lb)
Installation
Supports wall mount and desktop mount installation
Casing Material
PC + ABS
Certifications
CE
Storage Temperature
–10 °C to +55 °C (+14 °F to +131 °F)
Storage Humidity
10%–90% (RH)
Packaging Dimensions
254 mm × 211 mm × 61 mm (10.00" × 8.31" × 2.40") (L× W × H), standalone in the inner box
524 mm × 508 mm × 442 mm (20.63" × 20.00" × 17.40") (L × W × H), protective caseWi-Fi
Wi-Fi Standard
IEEE 802.11b/g/n/ax
Wi-Fi Frequency Range
2400-2483.5 MHz
Wi-Fi Power Transmission
≤20 dBm@2400-2483.5 MHz
