Built-in System

Operating System

Android 13.0

CPU

Quad-core A55

CPU Frequency

1.9 GHz

GPU

Mali G52MP2

RAM

8 GB

ROM

128 GB

Function

Operating System of External Module

Windows, macOS, Android, Linux, Google Chrome

Wi-Fi

Wi-Fi 5, 802.11a/b/g/n/ac

Wi-Fi Hotspot

Wi-Fi 5, 2.4 GHz and 5 GHz dual band

LCD Panel

Panel Dimensions

86 inch

Backlight

DLED

Aspect Ratio

16: 9

Brightness

350 cd/m² (typ.)

Resolution

3,840 (H) × 2,160 (V)

Viewing Angle

178° (H); 178° (V)

Lifespan

≥50,000 hrs

Display Color

1.07 billion

Refresh Rate

60 Hz

Static Contrast

IPS: 1200 (typ.)

Response Time

8 ms (typ.)

Camera

Pixel

13 MP

Distortion

0.087

Max. Resolution

15 fps@Mjpg 4208 × 3120

Field of View

H: 123°; V: 102.3°; D: 84.8°

Device Ports

Light Sensor

Yes

Front Button

7 buttons (home, touch lock, increase the volume, decrease the volume, signal source, return and power supply)

Front Ports

Type-C × 1; HDMI IN × 1; Touch Type-B × 1; USB Type-A × 3

Network Port

1 (100 Mbps)

Wi-Fi

Yes

Wi-Fi Standard

Wi-Fi Station: 802.11b/g/n/a/ac

Wi-Fi AP: 802.11b/g/n/a/ac

Wi-Fi Frequency Range

2400–2483.5 MHz;

5150–5250 MHz;

5250–5350 MHz;

5470–5725 MHz;

5725–5850 MHz;

MAX Power Transmission (Wi-Fi)

≤20 dBm@2400–2483.5 MHz;

≤23 dBm@5150–5250 MHz;

≤20 dBm@5250–5350 MHz;

≤27 dBm@5470–5725 MHz;

≤14 dBm@5725–5850 MHz;

Bluetooth

Yes

Bluetooth Standard

BT5.0 BR/EDR/BLE

Bluetooth Frequency Range

≤20 dBm@2400–2483.5 MHz

MAX Power Transmission (Bluetooth)

≤20 dBm

USB

USB 2.0 × 1; USB3.0 × 1; Touch USB2.0 × 1

RS-232

1 DB9 for controlling the device

Video Input

HDMI IN 2.0 × 2; AV IN × 1

Video Output

AV OUT × 1

Audio Output

3.5 mm stereo line out × 1 (coaxial)

Others

OPS slot × 1

IrDA

1

Type-C Port

Front Type-C × 1

Touchscreen

Touch Technology

Infrared touch technology

Response Time

≤6 ms

Touch Points

Android 20 Windows 40

Valid Touch

2 mm

Writing Mode

Finger and stylus pen (magnetic)

Anti-light Interference

Anti-glare tempered glass

Surface Hardness

＞7 hrs

Touch Resolution

32,767 × 32,767

Number of Multi-user Writing Points

5

Speaker

Frequency

150 Hz–20 kHz

Power

15 W × 2 (max)

Built-in Speaker

2

Microphone

Pick-up Distance

8 m (26.25 ft)

Number of Microphones

8

AGC

Yes

Echo Cancellation

Yes

General

Power Supply

100–240V AC, 50/60 Hz

Power Consumption

≤450 W

Operating Temperature

0 °C to +55 °C (+32 °F to +131 °F)

Storage Temperature

–10 °C to +55 °C (+14 °F to +131 °F)

Operating Humidity

20%–80% (RH)

Storage Humidity

20%–90% (RH)

Product Material

Metal

Protective Glass

4.0 mm anti-glare tempered glass

Casing Color (Frame/Rear)

Black

Product Dimensions

1,953.2 mm × 1,192 mm × 116.7 mm (76.90" × 46.93" × 4.59")

Frame Size

U: 61.5 mm, L/R: 17.6 mm, D: 28.3 mm (U: 2.42", L/R: 0.69", D: 1.11")

Packaging Dimensions

2,044 mm × 200 mm × 1,280 mm (80.47" × 7.87" × 50.39")

Net Weight

66 kg (145.51 lb)

Gross Weight

75 kg (165.35 lb)

Holes Distance

800 mm × 400 mm (31.50" × 15.75")

Installation

Wall mount or mobile bracket

Standby Power Consumption

≤0.5 W

Packing List

Smart interactive whiteboard × 1 Stylus pen ×2 Power cable × 1 Quick start guide × 1 Wall mount bracket × 1 Pack of wall mount screws × 1 Antenna × 4
