Display

Model

DHI-LM24-H200

LCD Technology

VA

Backlight

ELED

Screen Size

23.8 inch

Aspect Ratio

16:9

Viewing Size

527.04 (H) × 296.46 (V) mm

Viewing Angle

178° (H) / 178° (V)

Display Mode

Horizontal

Pixel Pitch

0.2745 mm × 0.2745 mm

Pixels Per Inch

92.55

Resolution

1920 (H) ×1080 (V)

Refresh Rate

100 Hz

Display Color

8 bit (6 bits+FRC)

Color Gamut

72% NTSC (typ.)

Brightness

250 cd/m² (typ.)

Contrast Ratio

4000:1

Response Time

OD 5 ms

Operation Hours

7 × 24 h

Lifespan

30,000 hrs

Device Ports

Input Port

1 × VGA (1920×1080@60 Hz), 1 × HDMI 1.4 (1920×1080@100 Hz), 1 × Audio

Speaker

2 × 1.5 W

Power & Environmental Conditions

Power Supply

12 VDC, 2 A

Power Type

Power adapter

Power Consumption

13 W (basic), 18 W (typ.), 21 W (max)

Standby Power Consumption

<0.5 W

Operating Temperature

0 °C to +40 °C (+32 °F to +104 °F)

Operating Humidity

10% – 85% (RH)

Storage Temperature

–20 °C to +60 °C (–4 °F to +140 °F)

Storage Humidity

5%–90% (RH)

General

Product Dimensions

540.4 mm × 325.2 mm × 48.4 mm (21.27" × 12.80" × 1.83") (W × H × D) without base

Package Size

606 mm × 405 mm × 125 mm (23.86" × 15.94" × 4.92") (W × H × D)

Frame Width

U/L/R/D: 3.4 mm/3.4 mm/3.4 mm/21 mm

Net Weight

2.9 kg (6.39 lb)

Gross Weight

4.0 kg (8.82 lb)

Casing Color

Black

Control Mode

Five-button

Wall Mount VESA

100 mm × 100 mm (3.94" × 3.94")

Accessory

Power adapter, base, HDMI cable, user's manual (QR code), QSG, legal and regulatory information, etc.

Certification

Certifications

CE EMC, CE LVD, CE ERP
