Camera

Image Sensor

1/3" CMOS

Max. Resolution

2560 (H) × 1440 (V)

Illumination Distance

Up to 30 m (98.43 ft) (IR)
Up to 20 m (65.62 ft) (Warm light)

Illuminator Number

1 (Warm light); 1 (IR light); 1 pairs (Red and blue alarm light)

Angle Adjustment

Pan: 0° to 360°
Tilt: -60 °to 0°
Rotation: 0° to 360°

PIR Sensor Distance

12 m (the height of device is 2.5 m, placed horizontally);
8 m (the height of the device is 2 m, placed at an angle of 30° from the horizontal)

Lens Type

Fixed-focal

Focal Length

3.6 mm

Max. Aperture

F1.6

Field of View

H: 78.4°; V: 42.4°; D: 92.4°

Audio and Video

Video Compression

H.265

Video Frame Rate

Main stream: 2560 × 1440@(1–15 fps)
sub stream: 640 × 360@(1–15 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Video Bit Rate

H.265: 32 kbps–4096 kbps

Day/Night

Auto(ICR)/Color/B/W

WDR

Yes

Motion Detection

OFF/ON (4 areas, rectangular)

Built-in MIC

Yes, built-in Mic

Built-in Speaker

Yes, built-in speaker

Audio Compression

G.711a

Network

Network Port

RJ-45 (10/100 Base-T)

Carrier Network System

(-EAU): FDD-LTE: B1/B3/B5/B7/B8/B20/B28;

Applicable regions: Europe, Middle East, Africa

Power class 3: 23dBm ±2.7dB

(-LA): FDD-LTE: B2/B3/B4/B5/B7/B8/B28/B66;

Applicable regions: Latin America

Power class 3: 23dBm ±2.7dB

Storage

Micro SD card (support max. 512 GB)

Management Software

DMSS; DSS Pro

Mobile Client

Android;iOS

General

Certifications

CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU;
CE-RED: Radio Equipment Directive 2014/53/EU

Power Supply

Built in 68Wh lithium battery

Charging:

USB Type-C

Power Consumption

Ultra power saving mode: 0.04 W
Power saving mode: 0.041 W
AOV mode: 0.197 W
Performance mode: 1.2 W

Operating Temperature

–20 °C to +60 °C (–4 °F to +140 °F)

Operating Humidity

≤95% (RH), non-condensing

Protection

IP66

Casing Material

Plastic

Product Dimensions

284 mm × 172 mm × 360 mm (11.57" × 6.77" × 14.17") (L × W × H)

Net Weight

1055 g (2.33 lb)

Battery

Battery Capacity

68 Wh
