PFM800-E
1 Channel Passive HDCVI Balun
>Real-time transmission over UTP CAT5E/6 cable.
>Passive, no need for power supply.
>With female BNC connector, and pluggable screw terminal connections.
>Passive, no need for power supply.
>With female BNC connector, and pluggable screw terminal connections.
- Specifications
- Accessories
- Download
Model PFM800-E Properties Transmission Signal 1 channel Transmission Distance HDCVI
720P: max.400m(1312.34ft)
1080P: max.250m(820.21ft)Category Type UTP CAT 5E/6 Video Transmission Properties And Port Coaxial Video Connector BNC-M Twisted-pair Video Connector Push-terminal Compatible Format HDCVI/AHD/TVI/CVBS Resolution 720P/1080P Anti-interference ＞60db Protection ESD 1a contact discharge electricity level 3 1b air discharge electricity level 3 Per: IEC61000-4-2 Coaxial Cable Connector 2KV(common-code) Per: IEC1000-4-5 UTP Cable Connector 2KV(different-code), 4KV(common-code), Per: IEC1000-4-5 Impedance BNC Male 75 ohms UTP Cable 100 ohms Physical Properties Dimension(L*W*H) 180mm*19mm*16mm(7.09”x0.75”x0.63”) Shell ABS Color Black N.W. 42g/pair (0.09lb) Stability MTBF ＞10000h Environmental Operating Temperature -10℃~+55℃(14℉~131℉) Storage Temperature -20℃~+70℃(-4℉~158℉) Humidity 0~95%(non-condensing)
_1_thumb.png)
- Datasheet
- User Manual
- Drawings
- A&E Document
- Images
- NameTo view
No Data!
