Camera

Image Sensor

Channel 1 (Panoramic): 1/1.8" CMOS
Channel 2 (PTZ): 1/1.8" CMOS

Max. Resolution

Channel 1 (Panoramic): 4096 (H) × 1800 (V)
Channel 2 (PTZ): 2688 (H) × 1520 (V)

ROM

Channel 1 (Panoramic): 8 GB
Channel 2 (PTZ): 4 GB

RAM

Channel 1 (Panoramic): 4 GB
Channel 2 (PTZ): 2 GB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

Channel 1 (Panoramic):
0.0005 lux@F1.0 (Color, 30 IRE)
0.0001 lux@F1.0 (B/W, 30 IRE)
Channel 2 (PTZ):
0.001 lux@F1.6 (Color, 30 IRE)
0.0001 lux @F1.6 (B/W, 30 IRE)
0 lux (Illuminator on)

S/N Ratio

>56 dB

Illumination Distance

Channel 1 (Panoramic): NA
Channel 2 (PTZ): IR Up to 150 m (492.13 ft)

Warm Up to 100 m (328.09 ft)

Illuminator On/Off Control

Auto; Manual; Zoomprio

Illuminator Number

Channel 1 (Panoramic): NA
Channel 2 (PTZ): 6 (Multi-core (IR + warm) light)

Angle Adjustment

Pan: 0° to 360° ;
Tilt: –10° to 180°, auto flip 180°

Gradienter

Yes

Lens

Lens Type

Channel 1 (Panoramic): Fixed-focal
Channel 2 (PTZ): Vari-focal

Lens Mount

Channel 1 (Panoramic): M16
Channel 2 (PTZ): Module

Focal Length

Channel 1 (Panoramic): 2.8 mm
Channel 2 (PTZ): 5.2 mm–210 mm

Max. Aperture

Channel 1 (Panoramic): F1.0
Channel 2 (PTZ): F1.6–F5.0

Field of View

Channel 1 (Panoramic): H: 180°; V: 103°;
Channel 2 (PTZ): H: 60.8°–2.8°; V: 35.9°–1.7°; D: 67.7°–3.3°

Iris Control

Channel 1 (Panoramic): Fixed
Channel 2 (PTZ): Auto

Close Focus Distance

Channel 1 (Panoramic): 1.4 m (4.59 ft)
Channel 2 (PTZ): 0.5 m (1.64 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

Channel 1 (Panoramic)

57.9 m

(189.96 ft)

23.2 m

(76.11 ft)

11.6 m

(38.06 ft)

5.8 m

(19.03 ft)

Channel 2 (PTZ)

2648.2 m

(8688.32 ft)

1046.1 m

(3432.09 ft)

530.0 m

(1738.85 ft)

264.8 m

(868.77 ft)

Intelligence

Intelligence Notes

Channel 1 (Panoramic): Perimeter protection, crowd map (Large-Scale AI Models), vehicle density, boat detection.
Channel 2 (PTZ): Perimeter protection, video metadata, face detection.

IVS (Perimeter Protection)

Channel 1 (Panoramic): Tripwire; intrusion; parking detection
Channel 2 (PTZ): Tripwire; intrusion; parking detection; crossing virtual fence; fast moving; abandoned object; missing object; crowd gathering; loitering detection

Face Detection

Channel 1 (Panoramic): NA
Channel 2 (PTZ):
Supports face detection, optimization,capturing pictures, uploading high-quality face snapshots, and face enhancement; Supports attributes extraction. 6 attributes and 8 expressions: Gender, age, glasses, expressions (angry, sad, hate, scary, surprise, calm, happy and confused), mask, mustache; Supports face cutout: Face, one-inch photo. Capturing strategies include optimization.

Vehicle Density

Channel 1 (Panoramic): Vehicle density; parking upper limit; traffic congestion; vehicle status alarm
Channel 2 (PTZ): NA

Crowd Distribution Map

Channel 1 (Panoramic): Crowd map (Large-Scale AI Models), global crowd density; crowd density in area; people counting in area; crowd status
Channel 2 (PTZ): NA

Video Metadata

Channel 1 (Panoramic): NA
Channel 2 (PTZ):
Motor vehicle, non-motor vehicle, face, and human body detection; optimization; capturing pictures; uploading high-quality face snapshots
Motor vehicle attributes: License plate, plate color, vehicle type, vehicle color, vehicle logo, vehicle model/year, sun visor, seatbelt., smoking, calling, ornament, and annual inspection sticker.
Non-motor vehicle attributes: Type, vehicle color, number of people, top type and color, and hat.
Human body attributes: Top and bottom type and color, bag, hat, gender, and umbrella.
Face attributes: Gender, age, facial expressions, glasses, face mask, and mustache.

Smart Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)

Smart Codec

Smart H.264+; Smart H.265+

Video Frame Rate

Channel 1 (Panoramic):
Main stream: 4096 × 1800@(1–25/30 fps)
sub stream: 1024 × 452@(1–25/30 fps)
third stream: 1920 × 832@(1–25/30 fps)
Channel 2 (PTZ):
Main stream: 2688 × 1520@(1–25/30 fps)
sub stream: 704 × 480@(1–25/30 fps)
third stream: 1920 × 1080@(1–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Streaming Capability

3 streams

Resolution

Channel 1 (Panoramic):
4096 × 1800; 3840 × 1680; 2880 × 1264; 2048 × 900; 1024 × 452; 1920 × 832; 1280 × 560;
Channel 2 (PTZ):
2688 × 1520; 2560 × 1440; 2304 × 1296; 1920 × 1080; 1280 × 960; 1280 × 720; 704 × 480; 640 × 480; 352 × 240

Bit Rate Control

VBR; CBR

Video Bit Rate

Channel 1 (Panoramic):
H.264: 64 kbps–16384 kbps;
H.265: 25 kbps–15831 kbps;
Channel 2 (PTZ):
H.264: 32 kbps–16384 kbps;
H.265: 12 kbps–11008 kbps

Day/Night

Channel 1 (Panoramic): NA
Channel 2 (PTZ): ICR

BLC

Yes

HLC

Yes

WDR

Channel 1 (Panoramic): 120 dB
Channel 2 (PTZ): 120 dB

White Balance

Auto; natural; street lamp; outdoor; manual; regional custom

Gain Control

Manual; Auto

Noise Reduction

3D NR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest (RoI)

Channel 1 (Panoramic): Yes (4 areas)
Channel 2 (PTZ): Yes (8 areas)

Image Stabilization

Channel 1 (Panoramic): NA
Channel 2 (PTZ): Gyroscope Image Stabilization (GIS)

Defog

Channel 1 (Panoramic): NA
Channel 2 (PTZ): Optical defog

Privacy Masking

Channel 1 (Panoramic): 4 areas (rectangle)

Channel 2 (PTZ): 24 areas (8 for each preset) (polygon)

Audio

Built-in MIC

Yes, built-in dual Mic

Built-in Speaker

Yes, built-in speaker

Audio Compression

PCM; G.711a; G.711Mu; G.726; G.723, G.711a by default

Alarm

Alarm Event

Channel 1 (Panoramic):
External alarm; No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; voltage detection; motion detection; video tampering; scene changing; audio detection; intensity change; tripwire; intrusion; parking detection; crowd density; traffic congestion; parking upper limit;
Channel 2 (PTZ):
Tripwire; intrusion; parking detection; crossing virtual fence; fast moving; abandoned object; missing object; crowd gathering; loitering detection; face detection; video metadata

Network

Network Port

RJ-45 (10/100/1000 Base-T)

SDK and API

Yes

Network Protocol

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P

Security

WSSE; Account lockout; Trusted execution; Generation and importing of X.509 certification; 802.1x; Security logs; Digest;IP/MAC filtering; HTTPS; Trusted upgrade; syslog; Trusted boot

Interoperability

ONVIF (Profile S/Profile G/Profile T); CGI

User/Host

20 (Total bandwidth: 400 M)

Storage

FTP; SFTP; Micro SD card (support max. 1 TB); NAS; SMB

Browser

IE: IE11; Chrome; Firefox

Management Software

DSS Pro

Function

AR Function

Yes

PTZ

Pan/Tilt Range

Pan: 0° to 360° endless
Tilt: –10° to 180°, auto flip 180°

Manual Control Speed

Pan: 0°/s–360°/s
Tilt: 0°/s–200°/s

Preset

300

Preset Speed

Pan: 0°/s–360°/s
Tilt: 0°/s–200°/s

Tour

8 (up to 32 presets per tour)

Pattern

5

Scan

5

Power-off Memory

Yes

Idle Motion

Tour;Preset; Pattern; Scan

Certification

Certifications

CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

Port

RS-485

1 (baud rate range: 1200 bps–115200 bps)

Audio Input

2 channels (terminal)

Audio Output

1 channel (terminal)

Alarm Input

3 channels in: wet contact, 5 mA 3–5 VDC

Alarm Output

2 channels out: dry contact, 1,000 mA 30 VDC/500 mA 50 VAC

Analog Output

1 channel (CVBS output: BNC)

Power Output

12 VDC power output, max. current 165 mA, peak current 700 mA

Power

Power Supply

36 VDC (±50%); PoE++ (802.3bt)

Power Consumption

Basic: 26.4 W (36 VDC);
Max.: 67.8 W (36 VDC) (Basic power consumption + WDR + intelligence on +Speaker+Heater+ LED on + PTZ operation)

Environment

Operating Temperature

–40 °C to +70 °C (–40 °F to +158 °F)

Operating Humidity

≤95%

Storage Temperature

–40 °C to +70 °C (–40 °F to +158 °F)

Storage Humidity

≤95%

Protection

IP67; IK10

Structure

Casing Material

Metal + plastic

Product Dimensions

Φ280.0 mm × 368.0 mm (Φ11.02" × 14.49")

Net Weight

8.8 kg (19.40 lb)

Gross Weight

12.2 kg (26.90 lb)
