IPC-PDBW82041-B360 EoL-L

4 × 5MP WizMind Multi-Sensor No-Splicing Panoramic Dome Network Camera

> 4 × 5MP 1/2.7" CMOS image sensor, low illuminance, high image definition
> 4-channel stream output, and each channel can output max. 5MP
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various
> Support 4-channel 120dB WDR
> The intelligent functions of 4 channels can be enabled at the same time
> Intelligent detection: Tripwire, intrusion, fast moving (the three
> FlexStream: The 4 channels of images can be viewed in a defined
> Web5.0 interface design, which is friendly to users, and easy for operation
> Built-in efficient IR LED illuminator, and the max. illumination distance is
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; 485; supports max. 256 G Micro SD
> 12V DC/POE power supply; 12V power output, and max. current 165mA;

> IP67, IK10 protection


  • Specifications
  • Accessories
  • Download
  • Video
  • Camera

    Image Sensor

    1/2.7”5Megapixel progressive CMOS

    Max. Resolution

    2592 (H) × 1944 (V)

    ROM

    32 GB

    RAM

    4 GB

    Scanning System

    Progressive

    Electronic Shutter Speed

    Auto/Manual 1/3 s–1/100,000 s

    Min. Illumination

    0.005 Lux@F1.7(Color,30IRE)

    0.0005 Lux@F1.7(B/W,30IRE)

    0 lux (Illuminator on)

    S/N Ratio

    > 56 dB

    Illumination Distance

    30 m (98.4 ft) (IR LED)

    Illuminator On/Off Control

    Auto/Manual

    Illuminator Number

    8 (IR LED)

    Pan/Tilt/Rotation Range

    Pan: 0°–360°
    Tilt: 0°–80°
    Rotation: 0°–355°

    Lens

    Lens Type

    Motorized vari-focal

    Mount Type

    φ14

    Focal Length

    2.8 mm–12 mm

    Max. Aperture

    F1.7

    Field of View

    Horizontal: 100°–36°
    Vertical: 74°–27°
    Diagonal: 133°–45°

    Iris Type

    Fixed

    Close Focus Distance

    0.8 m (2.6 ft)

    DORI Distance

    Lens

    Detect

    Observe

    Recognize

    Identify

    W

    66 m

    (216.5 ft)

    26.4 m

    (86.6 ft)

    13.2 m

    (43.3 ft)

    6.6 m

    (21.7ft)

    T

    140.4 m (460.6 ft)

    56.1 m

    (184.1 ft)

    28 m

    (91.9 ft)

    14 m

    (45.9 ft)

    Smart Event

    IVS

    Abandoned object; missing object

    Professional, intelligent

    IVS (Perimeter Protection)

    Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection

    Face Detection

    Face detection; track; optimization; snapshot; report high quality picture; face enhancement; face exposure; face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear), mask, beard; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting

    Intelligent Search

    Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.

    Video

    Video Compression

    H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)

    Smart Codec

    Smart H.265+/Smart H.264+

    Video Frame Rate

    Single Stream:
    Main stream: 5MP (1–25/30 fps)
    Sub stream: D1 (1–25/30 fps)
    Third stream: 2MP (1–25/30 fps)
    FlexStream:
    Main stream: 2MP (1–25/30 fps)
    Sub stream: D1 (1–25/30 fps)
    Third stream: 8MP (1–25/30 fps)

    Stream Capability

    3 streams

    Resolution

    Single Stream: 5M(2592×1944); 4M(2688×1520);

    3M(2048×1536);2M(1920×1080);720P(1280×720);

    D1(704× 576/704×480);CIF(352×288/352×240)

    FlexStream:8M(3296×2472);5M(2592×1944);

    2M(1600×1200);1.3M(1280×960);

    D1(704× 576/704×480);CIF(352×288/352×240)

    Bit Rate Control

    CBR/VBR

    Video Bit Rate

    H.264: 3 kbps–19456 kbps
    H.265: 3 kbps–19456 kbps

    Day/Night

    Auto (ICR)/Color/B/W

    BLC

    Yes

    HLC

    Yes

    WDR

    4 × 120 dB

    White Balance

    Auto/natural/street lamp/outdoor/manual/regional custom

    Gain Control

    Auto/Manual

    Noise Reduction

    3D NR

    Motion Detection

    OFF/ON (4 areas, rectangular)

    Region of Interest (RoI)

    Yes (4 areas)

    Smart Illumination

    Yes

    Image Rotation

    0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)

    Mirror

    Yes

    Privacy Masking

    4 areas

    Audio

    Audio Compression

    G.711a; G.711Mu; PCM; G.726; G.723

    Alarm

    Alarm Event

    No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; defocus detection; external alarm; face detection; safety exception; voltage detection

    Network

    Network

    RJ-45 (10/100/1000 Base-T)

    SDK and API

    Yes

    Cyber Security

    Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade

    Protocol

    IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP

    Interoperability

    ONVIF(Profile S/Profile G/Profile T); CGI; Milestone; Genetec; RTMP; P2P

    Storage

    FTP; SFTP; Micro SD card (support max. 256 G); NAS

    Browser

    IE: IE9 and later
    Chrome: 41.0 and later
    No-plug version: Safari and edge

    Management Software

    Smart PSS; DSS

    Mobile Phone

    IOS; Android

    Certification

    Certification

    CE-LVD: EN62368-1
    CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
    FCC: 47 CFR FCC Part 15, Subpart B
    UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

    Port

    RS-485

    1 (baud rate range: 1200 bps–115200 bps)

    Audio Input

    1 channel (RCA port)

    Audio Output

    1 channel (RCA port)

    Alarm Input

    3 channel in: 5mA 3V–5V DC

    Alarm Output

    2 channel out: 300mA 12V DC

    Power

    Power Supply

    12V DC/POE( 802.3at )

    Power Consumption

    Basic power consumption: 8.1W (12V DC); 9W (PoE)
    Max. power consumption (ICR + IR intensity): 21.5W (12V DC); 22.2W (POE+)

    Environment

    Operating Conditions

    –30°C to +60°C (–22°F to +140°F)/Less than 95% RH

    Storage Conditions

    –30°C to +60°C (–22°F to +140°F)

    Protection Grade

    IP67; IK10

    Structure

    Casing

    Metal + Plastic

    Dimensions

    286.1 mm × 111.3 mm (11.3" × 4.4")

    Net Weight

    2.75 kg (8.9 lb)

    Gross Weight

    4.5 kg (11.0 lb)
