PFM378-B100-WB

Integrated Solar Power System (without Lithium Battery)

> Integrated design, easy to install.
> Pole mount.
> Flexible angle adjustment of the solar panel and the camera.
> 100W Monocrystalline solar panel.
> Built sturdy to resist storms with sustained winds up to 117 km/h.
> Remote monitoring available through the mobile app.
> Maximum Power Point Tracking (MPPT) charging controller.
> RS-485 communication function.
> Electric protection.
  • Specifications
  • Accessories
  • Download
  • Solar Panel

    Type

    Monocrystalline silicon

    Max. Power

    100 W

    Output Voltage

    18.8 VDC

    Solar Cell Efficiency

    21%

    Max. Mechanical Load

    5400 Pa

    Controller

    Type

    MPPT

    Operating Voltage

    12 VDC

    Rated Charging Current

    10 A

    Rated discharge current

    10 A

    MPPT Tracking Efficiency

    ≥ 99%

    Communication Mode

    RS485

    Operating Temperature

    –20 °C to +60 °C (–4 °F to +140 °F)

    Rated Charging Power

    130 W

    Over-discharge Protection Voltage

    11.1 VDC

    Others

    Over-temperature ,over-discharge,overa-voltage and low-temperature protection of battery; overload and short circuit protection of load.

    Port

    Power Output

    Φ5.5 mm × Φ2.1 mm × 12 mm

    (Φ0.22" × Φ0.08" × 0.47")

    RS–485

    Red: RS485-A
    Black: RS485-B

    Output Port

    CSA authorized M15 2-core waterproof connector (connected to lithium battery)

    General

    Main Body Material

    Q235

    IP Rating

    IP65

    Installation

    Pole mount, Φ80mm~Φ150mm

    Adjustable Angle

    Solar panel: H: 360°, V: 20°/40°/60°

    Camera: H: 360°, V: 0°–75°

    Product Dimensions

    815mm x 846.8mm x 893.3mm

    (32.1” x 33.3” x 35.2”)

    Packaging Dimensions

    880 mm × 765 mm × 275 mm (34.65" × 30.12" × 10.83")

    Packaging Method

    1 pc in each carton

    Net Weight

    20.1 kg (44.31 lb)

    Gross Weight

    23.8 kg (52.47 lb)

    Environment

    Operating Altitude

    < 3000 m (9842.5 ft)

    Applicable Area

    Areas with daily exposure to solar radiation for more than 3.5 hours

    Operating Temperature

    –20 °C to +60 °C (–4 °F to +140 °F)

    Operating Humidity

    < 95% (RH)

    Storage Temperature

    0 °C to 40 °C (32 °F to 104 °F)

    Storage Humidity

    < 95% (RH)

    Certifications

    Certifications

    CE: EN 55032:2015+A11:2020,EN 55035:2017+A11:2020,EN 55024:2010+A1:2015,EN 50130-4:2011+A1:2014

    UKCA: EN 55032:2015+A11:2020,EN 55035:2017+A11:2020,EN 55024:2010+A1:2015,EN 50130-4:2011+A1:2014
