Camera

Image Sensor

1/1.8" CMOS

Pixel

8MP

Shutter Mode

Single shutter

Electronic Shutter Speed

Auto/Manual 1/50 s–1/100,000 s

Noise Reduction

3D NR

S/N Ratio

> 56 dB

WDR

140 dB

Min. Illumination

0.0001 lux

Illuminator

Illuminator Number

3 illuminators (850 nm LED illuminator or 3500 K LED illuminator)

Illuminator Brightness Adjustment

brightness adjustable

Illumination Distance

23 m–30 m (75.46 ft–98.43 ft) (adjustable brightness)

Lane Coverage

1–3 lanes

Lens

Lens Type

Motorized vari-focal

Focal Length

8 mm–32 mm

Max. Aperture

Max. F1.6

Field of View

H: 42°–15°; V: 22.8°–8.4°; D: 48.7°–17.1°

Exposure Mode

Auto; Manual (Select from shutter values or customize shutter range)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

W

218 m

(715.04 ft)

87.2 m

(286.02 ft)

43.6 m

(143.01 ft)

21.8 m

(71.51 ft)

T

580 m

(1902.4 ft)

232 m

(760.96 ft)

116 m

(380.48 ft)

58 m

(190.24 ft)

Radar

Radar Frequency Range

61 GHz–62 GHz

Speed Measurement Accuracy

Analog speed measurement error: -2 km/h to +2 km/h
(-6,561.68 ft/h to 6,561.68 ft/h)
On-site speed measurement error:
Vehicle speed <100 km/h ( <328,083.99 ft/h): –2 km/h to
+2 km/h (–6,561.68 ft/h to 6,561.68 ft/h)
Vehicle speed ≥100 km/h (≥328,083.99 ft/h): ± 2%

Speed Detection Range

5 km/h–180 km/h

Target Detection with Radar

Up to 32

Function

Trigger Mode

Video trigger/Radar trigger

OSD Overlay

Time, address, device SN, lane No., plate number, plate color, vehicle logo, vehicle type, vehicle color, vehicle size, vehicle speed, country/region, event (violation name), and motorcycle attributes (type, number of people, and helmet)

Alarm Event

Storage full; storage error; external alarm; no storage card; license plate blocklist; illegal access; network disconnection; IP conflict; intrusion; unlicensed vehicle

Automatic Network Replenishment (ANR)

Platform and FTP (TF card is required)

Auto Registration

Yes

Restricted List/Trusted

List:Allowlist:10000/Blocklist:10000

Intelligence

Target Detection

Motor vehicle; motorcycle

ANPR

Adopts deep-learning algorithms to recognize license plate numbers and letters

Vehicle Type Recognition

Vehicle head: SUV, Large bus, sedan, light truck, pickup, heavy truck, medium truck, van, medium bus, MPV
Vehicle tail: SUV, large bus, sedan, light truck, pickup, heavy truck, medium truck, van

Vehicle Color Recognition

White, pink, black, red, yellow, gray, blue, green, dark orange, purple, brown, and silver gray

Vehicle Brand/Logo Recognition

Acura; Alfaromeo; Ashokleyland; Astonmartin; Audi; Baic; Bently; Benz; BMW; Buick; BYD; Cadillac; Chery; Chevrolet; Chrysler; Citroen; Dacia; Daihatsu; Datsun; Dodge; DS; Ferrari; Fiat; Force; Ford; Foton; Geely; GMC; Greatwall; Hino; Honda; Hyundai; Infiniti; Isuzu; Iveco; Jac; Jaguar; Jeep; Kia; Kinglong; Land; Lexus; Lifan; Lincoln; Mahindra; MAN; Maserati; Mazda; Mercury; MG; Mini; Mitsubishi; Nissan; Opel; Peugeot; Porsche; Renault; Rollsroyce; Saab; Scania; Seat; Skoda; Smart; Subaru; Suzuki; Tata; Tesla; Toyota; UD; Volkswagen; Volvo

Motor Vehicle Violation Capture

Speeding; driving slow; wrong-way driving; illegal lane change

Motorcycle Violation Capture

Captures traffic violations including carrying passenger, not wearing helmet, and wrong-way driving

Traffic Flow Detection

Traffic flow mode: Covers up to 4 lanes. Statistics on vehicle flow, average speed, vehicle type, lane occupancy, average time headway, average queue length, and road status. Supports data classification and generating statistics on lanes, vehicle type, speed, and the date. The results can be exported to the CSV file format.

Traffic Event

Motor vehicle illegal stopping on the roadway; traffic congestion

Video

Video Compression

H.265; H.264M; H.264H; MJPEG

Video Resolution

8MP (3840× 2160); 1080p (1920 × 1080); 720p (1280 × 720);

Video Frame Rate

50 Hz: Max. 25fps; default main stream( 3840 × 2160@25 fps) , sub stream( 1280 × 720@25 fps)
60 Hz: Max. 30fps; default main stream( 3840 × 2160@30 fps) , sub stream( 1280 × 720@30 fps)

Video Bit Rate

H.264: 32 kbps–32768 kbps
H.265: 32 kbps–32768 kbps
MJPEG: 512 kbps–32768 kbps

Bit Rate Control

VBR; CBR

White Balance

Auto; Manual; Natural; Street Lamp; Outdoor; Partial white balance

Edge Enhancement

Yes

HLC

Yes

BLC

Yes

Bad Pixel Correction

Yes

Gain Range

0-100


Composite Image

Supports combining up to 3 source images, and 1 closeup image into a composite image

Image Resolution

3840 (H) × 2160 (V) (OSD black background is not calculated in the pixels)

Image Encoding Format

JPEG

Image Tampering Prevention

Verifies watermarks in videos and images

Network

Network Port

1 × RJ-45 Ethernet port

SDK and API

Yes

Security

Authorized username and password, MAC address binding, HTTPS, and network access control

Network Protocol

IPv4; IPv6; DHCP; NTP; IP;HTTP; UDP; TCP

Interoperability

ONVIF (Profile S & Profile G & Profile T & Profile M)

Browser

Microsoft Edge
Chrome: Chrome 41 and earlier
Firefox: Firefox 49 and earlier
For Win 10 users, run the browser as administrator

Timing

NTP

Port

Storage

1, supports maximum 1 TB TF card local storage

RS-485

1

RS-232

1

Alarm Input

1 channel

Alarm Output

2 channels

General

Power Supply

PoE;12 VDC

Power Consumption

With light turned off < 8 W
With IR light turned on < 12 W
With warm light turned on < 17 W

Operating Temperature

–30 °C to +65 °C (–22 °F to +149 °F)

Storage Temperature

–30 °C to +65 °C (–22 °F to +149 °F)

Operating Humidity

10%–90% (RH), non-condensing

Storage Humidity

0%–90% (RH), non-condensing

Protection

IK10; IP68

Anti-corrosion Level

Basic Protection

Certifications

CE EMC:EN 61000-3-3;EN IEC 61000-3-2;EN 301 489-1;EN 301 489-51;EN 301 489-52;EN 301 511;EN 301 908-1;EN 301 908-2;EN 301 908-13;EN 305 550-2;EN IEC 62311
CE LVD:EN62368-1
CE RED:EN 61000-3-3;EN IEC 61000-3-2;EN 301 489-1;EN 301 489-51;EN 301 489-52;EN 301 511;EN 301 908-1;EN 301 908-2;EN 301 908-13;EN 305 550-2;EN IEC 62311
IK10:IEC60068-2-75:2014
IP68:IEC60529:2013

Product Dimensions

350 mm × 109 mm × 150 mm (13.78" × 4.29" × 5.91") (L × W × H)

Packaging Dimensions

400 mm × 197 mm × 171 mm (15.75" × 7.76" × 6.73") (L × W × H)

Net Weight

1.88 kg (4.14 lb)

Gross Weight

2.52 kg (5.56 lb)

Installation

Installs with universal mounting brackets, or as a side-mount with mounting brackets
