Omnidirectional Digital Microphone
> Picks up sound 6 m (19.69 ft) away in all directions.
> Collects to terminals through network cables, Bluetooth and USB Bluetooth receivers.
> Provides high audio fidelity with automatic gain technology.
> Wireless cascading of 2 devices.
| Function | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pick-up Distance | 6 m (19.69 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pickup Mode | 360° HD audio pickup | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Number of Microphones | 8 array, omni-directional | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Power | 1 × 5 W, 1 × 3 W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| S/N Ratio | 65 dBA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Frequency Response | 75 Hz–20 kHz | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Battery Capacity | 3.7 V, 4,400 mAh | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Charging | 5 V, 2 A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Battery Life on a Full Charge | 8 hour at the maximum audio call volume | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Sensitivity | –24 dBFS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Number of Cascade | 2 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Bluetooth Module | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Bluetooth Standard | BT5.3 BR/EDR/BLE | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Bluetooth Frequency Range | ≤20 dBm@2400–2483.5 MHz | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max Power Transmission (Bluetooth) | ≤20 dBm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Operating Distance | 10 m (31.81 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Connection | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Type-C Port | 1 (Audio IN/OUT and charging) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Button | 7 (Power, receive and ignore calls, mute, Bluetooth, volume up, volume down, cascading) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Indicator Light | Yes (Battery, volume and button) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| General | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Power Supply | Lithium battery or power supply through the Type-C port | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Product Dimensions | 126 mm × 126 mm × 34 mm (4.96" × 4.96" × 1.34") (L × W × H) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Packaging Dimensions | 156 mm × 156 mm × 64 mm (6.14" × 6.14" × 2.52") (L × W × H) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Net Weight | 0.4 kg (0.88 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Gross Weight | 0.62 kg (1.37 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Packing List | Omnidirectional digital microphone × 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Operating Temperature | 0 °C to +40 °C (+32 °F to +104 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Operating Humidity | 10%–90%, (RH) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Storage Humidity | 10%–90%, (RH) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Operating Altitude | <5,000 m (16404.20 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Dimensions (mm[inch]) |
