Camera

Image Sensor

Channel 1 (PT Lens): 1/3" CMOS
Channel 2 (Fixed Lens): 1/3" CMOS

Max. Resolution

Channel 1 (PT Lens): 2560 (H) × 1440 (V)
Channel 2 (Fixed Lens): 2560 (H) × 1440 (V)

ROM

128 MB

RAM

512 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

0.008 lux@F1.6 (Color,30 IRE)
0.0008 lux@F1.6( B/W,30 IRE)
0 lux (Illuminator on)

S/N Ratio

>56 dB

Illumination Distance

Up to 30 m (98.43 ft) (IR)
Up to 30 m (98.43 ft) (Warm light)

Illuminator On/Off Control

Auto; Manual

Illuminator Number

4 (IR LED); 4 (Warm light)

Lens

Lens Type

Channel 1 (PT Lens): Fixed-focal
Channel 2 (Fixed Lens): Fixed-focal

Lens Mount

M12

Focal Length

Channel 1 (PT Lens): 3.6 mm
Channel 2 (Fixed Lens): 3.6 mm

Max. Aperture

Channel 1 (PT Lens): F1.6
Channel 2 (Fixed Lens): F1.6

Field of View

Channel 1 (PT Lens): H: 78°; V: 42°; D: 92°
Channel 2 (Fixed Lens): H: 78°; V: 42°; D: 92°

Iris Control

Fixed

Close Focus Distance

Channel 1 (PT Lens): 1.5 m (4.92 ft)
Channel 2 (Fixed Lens): 1.5 m (4.92 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

Channel 1 (PT Lens)

78.0 m

(255.91 ft)

31.2 m

(102.36 ft)

15.6 m

(51.18 ft)

7.8 m

(25.59 ft)

Channel 2 (Fixed Lens)

78.0 m

(255.91 ft)

31.2 m

(102.36 ft)

15.6 m

(51.18 ft)

7.8 m

(25.59 ft)

Intelligence

SMD

SMD Plus

Smart Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG (Only supported by sub stream)

Smart Codec

Smart H.265+; Smart H.264+

Video Frame Rate

Channel 1 (PT Lens):
Main stream: 2560 × 1440@(1–25 fps)
sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–25 fps)
Channel 2 (Fixed Lens):
Main stream: 2560 × 1440@(1–25 fps)
sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–25 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Streaming Capability

2 streams

Resolution

Channel 1 (PT Lens):
4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240);
Channel 2 (Fixed Lens):
4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control

VBR; CBR

Video Bit Rate

H.264: 32 kbps–6144 kbps;
H.265: 32 kbps–6144 kbps

Day/Night

Auto(ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

120 dB

White Balance

Auto; natural; street lamp; outdoor; manual; regional custom

Gain Control

Auto/Manual

Noise Reduction

3D NR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest (RoI)

Yes (4 areas)

Smart Illumination

Yes

Smart Dual Light

Yes

Image Rotation

0°/180°

Mirror

Yes

Privacy Masking

4 areas

Audio

Built-in MIC

Yes, built-in Mic

Built-in Speaker

Yes, built-in speaker

Audio Compression

G.711a; G.711Mu; PCM; G.726

Alarm

Alarm Event

No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; SMD; security exception

Network

Network Port

RJ-45 (10/100 Base-T)

SDK and API

Yes

Network Protocol

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P; Auto Registration

Security

HTTPS; Trusted upgrade;Digest; WSSE; Account lockout; Trusted execution; Generation and importing of X.509 certification; Security logs; Trusted boot

Interoperability

ONVIF (Profile S & Profile G & Profile T); CGI

User/Host

20 (Total bandwidth: 48 M)

Storage

FTP; Micro SD card (support max. 256 GB)

Browser

IE;
Chrome;
Firefox

Management Software

Smart PSS Lite; DSS; DMSS

Mobile Client

Android;iOS

Function

Light Warning

Warm light warning
Flash/Solid on duration: 5 s–180 s
Flash frequency: high, medium, low

Sound Warning

Offers 3 sound alarms and supports importing custom sound alarms.
Sound: 0-100.
Play times can be set from 1 to 10.

PTZ

Pan/Tilt Range

Channel 1 (PT Lens): Pan: 0° to 350°; Tilt: 0° to 90°;
Channel 2 (Fixed Lens): Pan: 0° to 326°; Tilt: –10° to 15°

Manual Control Speed

Pan: 0.1°/s–55.4°/s; Tilt: 0.1°/s–29.3°/s

Preset

50

Preset Speed

Pan: 55.4°/s; Tilt: 29.3°/s

Power-off Memory

Yes

Idle Motion

Preset

Certification

Certifications

CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

Power

Power Supply

12 VDC (±30%); PoE (802.3af)

Power Consumption

Basic: 3.2 W (12 VDC); 4.2 W (PoE);
Max.: 8.6 W (12 VDC); 10.5 W (PoE) (intelligence on + WDR + illuminator on + PT rotation + speaker on)

Environment

Operating Temperature

–40 °C to +50 °C (–40 °F to +122 °F)

Operating Humidity

≤95% (RH), non-condensing

Storage Temperature

–40 °C to +50 °C (–40 °F to +122 °F)

Storage Humidity

≤95% (RH), non-condensing

Protection

IP66

Structure

Casing Material

Plastic

Product Dimensions

110.1 mm × 159.4 mm × 210 mm (4.33" × 6.28" × 8.27") (L × W × H)

Net Weight

0.62 kg (1.37 lb)

Gross Weight

0.85 kg (1.87 lb)
